RSM-3500-18

Max processing size: 3500 × 3300 × 1800 mm

Dimension of worktable: 1800 × 2250 mm

Main Motor: 11 kW

Water consumption: 6 m³/h

Outline dimension: 9300 × 5900 × 4500 mm

Gross weight: 7500 kg

Worktable bearing weight: About 35 tons

Voltage: 380 V / 50 Hz / 3 PH

RSM-3500-21

Max processing size: 3500 × 3300 × 2100 mm

Dimension of worktable: 2000 × 2250 mm

Main Motor: 15 kW

Water consumption: 6 m³/h

Outline dimension: 9800 × 6800 × 5300 mm

Gross weight: 9000 kg

Worktable bearing weight: About 50 tons

Voltage: 380 V / 50 Hz / 3 PH
